Muffle Furnace – TP Series

Muffle Furnace from Reflecta Laboratories are available in a variety of models to best suit your need. Please view the technical specifications and features below: * Program controlling temperature for TP series. * Heating wire is set in four sides of the furnace, anti-corrosion, prevent contamination * Special insulation design, low shell temperature. * SCR control, PID parameter self-setting. * Low energy consumption. * Multiple safety protection design over-temperature alarm, Power off when over-temperature/over-load. Manual or automatic switch without interference. * Built-in parameter password control function. * *Please note: Ceramic fiber muffle are manufactured upon order and may take up to 4 weeks to deliver
*Please note: Muffle furnaces are manufactured upon order and may take up to 4 weeks to deliver
• Model: [‘MX8-13T/TP’, ‘MX10-13T/TP’, ‘MX6-16TP’, ‘MX11-16TP’, ‘MX6-17TP’, ‘MX11-17TP’] • Max. Temp.(℃): [‘1300’, ‘1600’, ‘1700’] • Capacity(L): [‘8′, ’10’, ‘6’, ’11’, ‘6’, ’11’] • Temp. Accuracy: ±1℃
• Consumption(KW): [‘4’, ‘4’, ‘6’, ‘8’, ‘6’, ‘8’] • Power Supply: [‘110/220/380V±10%, 50/60HZ’, ‘220/380V±10%, 50/60HZ’] • Heating Rate: 0-30℃/min
• Rising Time(Empty): 30 minutes
• Temp.Uniformity: ±6℃
• Material: External material:Cold rolled steel carbon steel spraying Internal material:Ceramic inner chamber
• Heating Element: Nickel chromium alloy wire
• Temp. Control: Intelligent temperature controller
• Optional Accessory: Observation hole;Exhaust chimney; Furnace bottom plate;
• Function: Automatically power off once the door is opened;30 programmable periods;
• Internal Size(W*D*H)mm: [‘200*300*120’, ‘200*300*180’, ‘150*300*120’, ‘200*300*180’, ‘150*300*120’, ‘200*300*180’] • External Size(W*D*H)mm: [‘630*650*730’, ‘600*640*850’, ‘650*750*1000’, ‘700*750*1200’, ‘650*750*1000’, ‘700*750*1200’] • Package Size(W*D*H)mm: [‘710*910*920’, ‘770*860*990’, ‘800*900*1150’, ‘850*900*1350’, ‘800*900*1150’, ‘850*900*1350′] • Gross Weight(Kg): [’70’, ’75’, ‘180’, ‘220’, ‘180’, ‘220’]

• MX8-13T Muffle Furnace
• MX8-13TP Muffle Furnace
• MX10-13T Muffle Furnace
• MX10-13TP Muffle Furnace
• MX6-16TP Muffle Furnace
• MX11-16TP Muffle Furnace
• MX6-17TP Muffle Furnace
• MX11-17TP Muffle Furnace
• Program controlling temperature for TP series
• Heating wire is set in four sides of the furnace, anti-corrosion, prevent contamination
• Special insulation design, low shell temperature
• SCR control, PID parameter self-setting
• Low energy consumption
• Multiple safety protection design over-temperature alarm
• Power off when over-temperature/over-load
• Manual or automatic switch without interference
• Built-in parameter password control function
